Description
The CODECOM CHDS SPLICE PANEL has been designed to splice the incoming fibers from high density backbone cables and for any fiber splicing need.
Features and Applications
- Available in 1U, 2U and 4U options
- Up to 144F ribbon max splicing per tray
- Up to 12 trays in 4U (1728F ribbon)
- Front access only
- Trays made of flame-retardant Nylon + Glass fill
Specifications
- Mounting type: Rack 19 inch
- Height: 1U, 2U, 4U
- Material: Metal body – cold rolled steel
- Ip rating: IP 20
- Dimension 1U: 488.9 X 244.7 X 43.8 MM
- Dimension 2U: 488.9 X 244.7 X 88 MM
- Dimension 4U: 488.9 X 244.7 X 176 MM
